| Media | Coolant etc. |
| Max. Pressure | Standard : 70 kgf/cm² High : 100 kgf/cm² |
| Max. Temperature | 120℃ |
| Max. Rotation Speed | Standard : 12,000 rpm High : 18,000 rpm |
◎ 사용유체, 온도, 압력, RPM에 따라 재질 변경됩니다. 문의를 바랍니다.
◎ High Speed 사용시 반드시 기술부에 문의 바랍니다.
| MODEL | B | A | L | L1 | L2 | L3 | H | O | D | D1 |
| MK411S-A8A-M1A1 | PT 1/4" | M16 x1.5 (RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø16.025 |
| MK411S-A8A-M1A2 | M16 x1.5 (LH) | ø16.007 | ||||||||
| MK411S-A8A-M2A1 | M16 x 1.5 (RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø17.993 | |
| MK411S-A8A-M2A2 | M16 x 1.5 (LH) | ø17.988 | ||||||||
| MK411S-B8A-M1A1 | PF 1/4" | M16 x 1.5 (RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø16.025 |
| MK411S-B8A-M1A2 | M16 x 1.5 (LH) | ø16.007 | ||||||||
| MK411S-B8A-M2A1 | M16 x 1.5 (RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø17.993 | |
| MK411S-B8A-M2A2 | M16 x 1.5 (LH) | ø17.988 | ||||||||
| MK411S-C8A-M1A1 | NPT 1/4" | M16 x 1.5 (RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø16.025 |
| MK411S-C8A-M1A2 | M16 x 1.5 (LH) | ø16.007 | ||||||||
| MK411S-C8A-M2A1 | M16 x 1.5 (RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø17.993 | |
| MK411S-C8A-M2A2 | M16 x 1.5 (LH) | ø17.988 | ||||||||
| MK411S-A10A-M1A1 | PT 3/8" | M16 x 1.5 (RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø16.025 |
| MK411S-A10A-M1A2 | M16 x 1.5 (LH) | ø16.007 | ||||||||
| MK411S-A10A-M2A1 | M16 x 1.5 (RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø17.993 | |
| MK411S-A10A-M2A2 | M16 x 1.5 (LH) | ø17.988 | ||||||||
| MK411S-B10A-M1A1 | PF 3/8" | M16 x 1.5 (RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø16.025 |
| MK411S-B10A-M1A2 | M16 x 1.5 (LH) | ø16.007 | ||||||||
| MK411S-B10A-M2A1 | M16 x 1.5 (RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø17.993 | |
| MK411S-B10A-M2A2 | M16 x 1.5 (LH) | ø17.988 | ||||||||
| MK411S-C10A-M1A1 | NPT 3/8" | M16 x 1.5 (RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø16.025 |
| MK411S-C10A-M1A2 | M16 x 1.5 (LH) | ø16.007 | ||||||||
| MK411S-C10A-M2A1 | M16 x 1.5 (RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø17.993 | |
| MK411S-C10A-M2A2 | M16 x 1.5 (LH) | ø17.988 | ||||||||
| MK411S-A8A-U1A1 | PT 1/4" | 5/8-18 UNF(RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø15.872 |
| MK411S-A8A-U1A2 | 5/8-18 UNF(LH) | ø15.860 | ||||||||
| MK411S-A8A-U2A1 | 5/8-18 UNF(RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø16.65 | |
| MK411S-A8A-U2A2 | 5/8-18 UNF(LH) | ø16.637 | ||||||||
| MK411S-B8A-U1A1 | PF 1/4" | 5/8-18 UNF(RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø15.872 |
| MK411S-B8A-U1A2 | 5/8-18 UNF(LH) | ø15.860 | ||||||||
| MK411S-B8A-U2A1 | 5/8-18 UNF(RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø16.65 | |
| MK411S-B8A-U2A2 | 5/8-18 UNF(LH) | ø16.637 | ||||||||
| MK411S-C8A-U1A1 | NPT 1/4" | 5/8-18 UNF(RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø15.872 |
| MK411S-C8A-U1A2 | 5/8-18 UNF(LH) | ø15.860 | ||||||||
| MK411S-C8A-U2A1 | 5/8-18 UNF(RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø16.65 | |
| MK411S-C8A-U2A2 | 5/8-18 UNF(LH) | ø16.637 | ||||||||
| MK411S-A10A-U1A1 | PT 3/8" | 5/8-18 UNF(RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø15.872 |
| MK411S-A10A-U1A2 | 5/8-18 UNF(LH) | ø15.860 | ||||||||
| MK411S-A10A-U2A1 | 5/8-18 UNF(RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø16.65 | |
| MK411S-A10A-U2A2 | 5/8-18 UNF(LH) | ø16.637 | ||||||||
| MK411S-B10A-U1A1 | PF 3/8" | 5/8-18 UNF(RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø15.872 |
| MK411S-B10A-U1A2 | 5/8-18 UNF(LH) | ø15.860 | ||||||||
| MK411S-B10A-U2A1 | 5/8-18 UNF(RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø16.65 | |
| MK411S-B10A-U2A2 | 5/8-18 UNF(LH) | ø16.637 | ||||||||
| MK411S-C10A-U1A1 | NPT 3/8" | 5/8-18 UNF(RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø15.872 |
| MK411S-C10A-U1A2 | 5/8-18 UNF(LH) | ø15.860 | ||||||||
| MK411S-C10A-U2A1 | 5/8-18 UNF(RH) | 112 | 29 | 5 | 11.5 | 24 | 6 | ø45 | ø16.65 | |
| MK411S-C10A-U2A2 | 5/8-18 UNF(LH) | ø16.637 |
