| Media | Steam |
| Max. Pressure | 12 kgf/cm² |
| Max. Temperature | Steam : 180℃ |
| Max. Rotation Speed | 1,000 rpm |
사용유체, 온도, 압력, RPM에 따라 재질 변경됩니다.
문의를 바랍니다.
| MODEL | B | A | C | L | L1 | L2 | L3 | H | D | D1 | |
| MK272S-20A-AE1 | PT 3/4" | PT 3/4" (RH) | PT 1/2" | 262 | 190 | 55 | 23 | 41 | 107 | 17 | |
| MK272S-20A-AE2 | PT 3/4" (LH) | ||||||||||
| MK272S-20A-BE1 | PF 3/4" | PF 3/4" (RH) | |||||||||
| MK272S-20A-BE2 | PF 3/4" (LH) | ||||||||||
| MK272S-20A-CE1 | NPT 3/4" | NPT 3/4" (RH) | |||||||||
| MK272S-20A-CE2 | NPT 3/4" (LH) | ||||||||||
| MK272S-25A-AF1 | PT 1" | PT 1" (RH) | PT 3/4" | 262 | 190 | 55 | 23 | 46 | 115 | 22 | |
| MK272S-25A-AF2 | PT 1" (LH) | ||||||||||
| MK272S-25A-BF1 | PF 1" | PF 1" (RH) | |||||||||
| MK272S-25A-BF2 | PF 1" (LH) | ||||||||||
| MK272S-25A-CF1 | NPT 1" | NPT 1" (RH) | |||||||||
| MK272S-25A-CF2 | NPT 1" (LH) | ||||||||||
| MK272S-32A-AG1 | PT 1" | PT 1 1/4" (RH) | PT 3/4" | 262 | 190 | 57 | 27 | 50 | 118 | 30 | |
| MK272S-32A-AG2 | PT 1 1/4" (LH) | ||||||||||
| MK272S-32A-BG1 | PF 1" | PF 1 1/4" (RH) | |||||||||
| MK272S-32A-BG2 | PF 1 1/4" (LH) | ||||||||||
| MK272S-32A-CG1 | NPT 1" | NPT 1 1/4" (RH) | |||||||||
| MK272S-32A-CG2 | NPT 1 1/4" (LH) | ||||||||||
| MK272S-40A-AH1 | PT 1 1/4" | PT 1 1/2" (RH) | PT 1" | 298 | 212 | 64 | 29 | 54 | 132 | 35 | |
| MK272S-40A-AH2 | PT 1 1/2" (LH) | ||||||||||
| MK272S-40A-BH1 | PF 1 1/4" | PF 1 1/2" (RH) | |||||||||
| MK272S-40A-BH2 | PF 1 1/2" (LH) | ||||||||||
| MK272S-40A-CH1 | NPT 1 1/4" | NPT 1 1/2" (RH) | |||||||||
| MK272S-40A-CH2 | NPT 1 1/2" (LH) | ||||||||||
| MK272S-50A-AJ1 | PT 1 1/2" | PT 2" (RH) | PT 1 1/4" | 343 | 240 | 64 | 29 | 60 | 154 | 47 | |
| MK272S-50A-AJ2 | PT 2" (LH) | ||||||||||
| MK272S-50A-BJ1 | PF 1 1/2" | PF 2" (RH) | |||||||||
| MK272S-50A-BJ2 | PF 2" (LH) | ||||||||||
| MK272S-50A-CJ1 | NPT 1 1/2" | NPT 2" (RH) | |||||||||
| MK272S-50A-CJ2 | NPT 2" (LH) | ||||||||||
