| Media | Air, Gas, Water etc. |
| Max. Pressure | 10 kgf/cm² |
| Max. Temperature | 120℃ |
| Max. Rotation Speed |
8A~25A 1,500rpm 32A~50A 1,000rpm |
사용유체, 온도, 압력, RPM에 따라 재질 변경됩니다.
문의를 바랍니다.
| MODEL | A | B | L | L1 | L2 | L3 | H | D | D1 |
| MK101S-6A-AA1 | PT 1/8" | PT 1/8" (RH) | 69 | 60 | 22 | 11 | 16 | ø28.5 | ø3 |
| MK101S-6A-AA2 | PT 1/8" (LH) | ||||||||
| MK101S-6A-BA1 | PF 1/8" | PF 1/8" (RH) | |||||||
| MK101S-6A-BA2 | PF 1/8" (LH) | ||||||||
| MK101S-6A-CA1 | NPT 1/8" | NPT 1/8" (RH) | |||||||
| MK101S-6A-CA2 | NPT 1/8" (LH) | ||||||||
| MK101S-8A-AB1 | PT 1/4" | PT 1/4" (RH) | 83 | 72.5 | 24 | 13 | 19 | ø39 | ø6 |
| MK101S-8A-AB2 | PT 1/4" (LH) | ||||||||
| MK101S-8A-BB1 | PF 1/4" | PF 1/4" (RH) | |||||||
| MK101S-8A-BB2 | PF 1/4" (LH) | ||||||||
| MK101S-8A-CB1 | NPT 1/4" | NPT 1/4" (RH) | |||||||
| MK101S-8A-CB2 | NPT 1/4" (LH) | ||||||||
| MK101S-10A-AC1 | PT 3/8" | PT 3/8" (RH) | 93.5 | 80.5 | 26 | 16 | 22 | ø44 | ø9 |
| MK101S-10A-AC2 | PT 3/8" (LH) | ||||||||
| MK101S-10A-BC1 | PF 3/8" | PF 3/8" (RH) | |||||||
| MK101S-10A-BC2 | PF 3/8" (LH) | ||||||||
| MK101S-10A-CC1 | NPT 3/8" | NPT 3/8" (RH) | |||||||
| MK101S-10A-CC2 | NPT 3/8" (LH) | ||||||||
| MK101S-15A-AD1 | PT 1/2" | PT 1/2" (RH) | 110 | 93 | 31 | 16 | 27 | ø54 | ø12.5 |
| MK101S-15A-AD2 | PT 1/2" (LH) | ||||||||
| MK101S-15A-BD1 | PF 1/2" | PF 1/2" (RH) | |||||||
| MK101S-15A-BD2 | PF 1/2" (LH) | ||||||||
| MK101S-15A-CD1 | NPT 1/2" | NPT 1/2" (RH) | |||||||
| MK101S-15A-CD2 | NPT 1/2" (LH) | ||||||||
| MK101S-20A-AE1 | PT 3/4" | PT 3/4" (RH) | 147 | 127 | 26 | 20 | 32 | ø70 | ø17 |
| MK101S-20A-AE2 | PT 3/4" (LH) | ||||||||
| MK101S-20A-BE1 | PF 3/4" | PF 3/4" (RH) | |||||||
| MK101S-20A-BE2 | PF 3/4" (LH) | ||||||||
| MK101S-20A-CE1 | NPT 3/4" | NPT 3/4" (RH) | |||||||
| MK101S-20A-CE2 | NPT 3/4" (LH) | ||||||||
| MK101S-25A-AF1 | PT 1" | PT 1" (RH) | 139 | 116 | 42 | 22 | 40 | ø74 | ø20 |
| MK101S-25A-AF2 | PT 1" (LH) | ||||||||
| MK101S-25A-BF1 | PF 1" | PF 1" (RH) | |||||||
| MK101S-25A-BF2 | PF 1" (LH) | ||||||||
| MK101S-25A-CF1 | NPT 1" | NPT 1" (RH) | |||||||
| MK101S-25A-CF2 | NPT 1" (LH) | ||||||||
| MK101S-32A-AG1 | PT 1 1/4" | PT 1 1/4" (RH) | 177 | 148 | 50 | 28 | 52 | ø90 | ø30 |
| MK101S-32A-AG2 | PT 1 1/4" (LH) | ||||||||
| MK101S-32A-BG1 | PF 1 1/4" | PF 1 1/4" (RH) | |||||||
| MK101S-32A-BG2 | PF 1 1/4" (LH) | ||||||||
| MK101S-32A-CG1 | NPT 1 1/4" | NPT 1 1/4" (RH) | |||||||
| MK101S-32A-CG2 | NPT 1 1/4" (LH) | ||||||||
| MK101S-40A-AH1 | PT 1 1/2" | PT 1 1/2" (RH) | 193 | 161 | 59 | 30 | 55 | ø95 | ø35 |
| MK101S-40A-AH2 | PT 1 1/2" (LH) | ||||||||
| MK101S-40A-BH1 | PF 1 1/2" | PF 1 1/2" (RH) | |||||||
| MK101S-40A-BH2 | PF 1 1/2" (LH) | ||||||||
| MK101S-40A-CH1 | NPT 1 1/2" | NPT 1 1/2" (RH) | |||||||
| MK101S-40A-CH2 | NPT 1 1/2" (LH) |
