| Media | Air, Water, Oil, Grease etc. |
| Max. Pressure | 30~250 kgf/cm² |
| Max. Temperature | 120℃ |
| Max. Rotation Speed | 20 rpm |
사용유체, 온도, 압력, RPM에 따라 재질 변경됩니다.
문의를 바랍니다.
| MODEL | A | B | L | L1 | L2 | D | H | |||
| M | R | |||||||||
| MKTJ-8A-AB | 8A | 1/4" | 62 | 42 | 38 | 13.5 | 6 | 20 | ||
| MKTJ-10A-AC | 10A | 3/8" | 74 | 49 | 43 | 17 | 9 | 24 | ||
| MKTJ-15A-AD | 15A | 1/2" | 85.5 | 58 | 51 | 19 | 12 | 28 | ||
| MKTJ-20A-AE | 20A | 3/4" | 105.5 | 70 | 62 | 21 | 16 | 35 | ||
| MKTJ-25A-AF | 25A | 1" | 123 | 80 | 71 | 23 | 20 | 41 | ||
| MKTJ-32A-AG | 32A | 1 1/4" | 143 | 89 | 80 | 26 | 30 | 55 | ||
| MKTJ-40A-AH | 40A | 1 1/2" | 152 | 92 | 83.5 | 26 | 35 | 55 | ||
| MKTJ-50A-AJ | 50A | 2" | 175 | 109 | 98 | 33 | 40 | 70 | ||
