| Media | Air, Gas, Water etc. |
| Max. Pressure |
Air : 10 kgf/cm² Water, Hydraulic oil : 20A~25A 23 kgf/cm² 32A~50A 18 kgf/cm² 65A~80A 13 kgf/cm² |
| Max. Temperature | 120℃ |
| Max. Rotation Speed |
15A~25A 2,000rpm 32A~50A 1,000rpm 65A~80A 650rpm |
사용유체, 온도, 압력, RPM에 따라 재질 변경됩니다.
문의를 바랍니다.
| MODEL | B | A | C | L | L1 | L2 | L3 | H | D | D1 | D2 | D3 | |
| MK202S-20A-AE1 | PT 3/4" | PT 3/4" (RH) | PT 1/2" | 198 | 139 | 36 | 20 | 41 | ø74 | 37 | ø13.8 | ø17 | |
| MK202S-20A-AE2 | PT 3/4" (LH) | ||||||||||||
| MK202S-20A-BE1 | PF 3/4" | PF 3/4" (RH) | |||||||||||
| MK202S-20A-BE2 | PF 3/4" (LH) | ||||||||||||
| MK202S-20A-CE1 | NPT 3/4" | NPT 3/4" (RH) | |||||||||||
| MK202S-20A-CE2 | NPT 3/4" (LH) | ||||||||||||
| MK202S-25A-AF1 | PT 1" | PT 1" (RH) | PT 3/4" | 201 | 141 | 42 | 22 | 41 | ø74 | 37 | ø17.3 | ø22 | |
| MK202S-25A-AF2 | PT 1" (LH) | ||||||||||||
| MK202S-25A-BF1 | PF 1" | PF 1" (RH) | |||||||||||
| MK202S-25A-BF2 | PF 1" (LH) | ||||||||||||
| MK202S-25A-CF1 | NPT 1" | NPT 1" (RH) | |||||||||||
| MK202S-25A-CF2 | NPT 1" (LH) | ||||||||||||
| MK202S-32A-AG1 | PT 1 1/4" | PT 1 1/4" (RH) | PT 3/4" | 238 | 165 | 54 | 27 | 49 | ø90 | 45 | ø21.7 | ø30 | |
| MK202S-32A-AG2 | PT 1 1/4" (LH) | ||||||||||||
| MK202S-32A-BG1 | PF 1 1/4" | PF 1 1/4" (RH) | |||||||||||
| MK202S-32A-BG2 | PF 1 1/4" (LH) | ||||||||||||
| MK202S-32A-CG1 | NPT 1 1/4" | NPT 1 1/4" (RH) | |||||||||||
| MK202S-32A-CG2 | NPT 1 1/4" (LH) | ||||||||||||
| MK202S-40A-AH1 | PT 1 1/2" | PT 1 1/2" (RH) | PT 1" | 275 | 190 | 64 | 30 | 56 | ø106 | 53 | ø27.2 | ø35 | |
| MK202S-40A-AH2 | PT 1 1/2" (LH) | ||||||||||||
| MK202S-40A-BH1 | PF 1 1/2" | PF 1 1/2" (RH) | |||||||||||
| MK202S-40A-BH2 | PF 1 1/2" (LH) | ||||||||||||
| MK202S-40A-CH1 | NPT 1 1/2" | NPT 1 1/2" (RH) | |||||||||||
| MK202S-40A-CH2 | NPT 1 1/2" (LH) | ||||||||||||
| MK202S-50A-AJ1 | PT 2" | PT 2" (RH) | PT 1 1/4" | 296 | 191 | 65 | 30 | 61 | ø117 | 58.5 | ø34 | ø47 | |
| MK202S-50A-AJ2 | PT 2" (LH) | ||||||||||||
| MK202S-50A-BJ1 | PF 2" | PF 2" (RH) | |||||||||||
| MK202S-50A-BJ2 | PF 2" (LH) | ||||||||||||
| MK202S-50A-CJ1 | NPT 2" | NPT 2" (RH) | |||||||||||
| MK202S-50A-CJ2 | NPT 12" (LH) | ||||||||||||
| MK202S-65A-AK1 | PT 3" | PT 2 1/2" (RH) | PT 1 1/2" | 339 | 227 | 70 | 35 | 75 | ø145 | 77.5 | ø45 | ø60 | |
| MK202S-65A-AK2 | PT 2 1/2" (LH) | ||||||||||||
| MK202S-65A-BK1 | PF 3" | PF 2 1/2" (RH) | |||||||||||
| MK202S-65A-BK2 | PF 2 1/2" (LH) | ||||||||||||
| MK202S-65A-CK1 | NPT 3" | NPT 2 1/2" (RH) | |||||||||||
| MK202S-65A-CK2 | NPT 2 1/2" (LH) | ||||||||||||
