| Media | Air, Hydraulic oil etc. |
| Max. Pressure | Air : 10 kgf/cm² Hydraulic oil : 200 kgf/cm² |
| Max. Temperature | 120℃ |
| Max. Rotation Speed | 250 rpm |
사용유체, 온도, 압력, RPM에 따라 재질 변경됩니다.
문의를 바랍니다.
| MODEL | A | B | L | L1 | L2 | L3 | L4 | D | H |
| MK522S-A8A-AF1 | PT 1/4" | PT 1" (RH) | 139 | 32 | 77 | 33 | 20 | ø74 | 46 |
| MK522S-A8A-AF2 | PT 1" (LH) | ||||||||
| MK522S-B8A-BF1 | PF 1/4" | PF 1" (RH) | |||||||
| MK522S-B8A-BF2 | PT 1" (LH) | ||||||||
| MK522S-C8A-CF1 | NPT 1/4" | NPT 1" (RH) | |||||||
| MK522S-C8A-CF2 | NPT 1" (LH) | ||||||||
| MK521S-A10A-AF1 | PT 3/8" | PT 1" (RH) | 145 | 32 | 77 | 33 | 20 | ø74 | 46 |
| MK522S-A10A-AF2 | PT 1" (LH) | ||||||||
| MK522S-B10A-BF1 | PF 3/8" | PF 1" (RH) | |||||||
| MK522S-B10A-BF2 | PF 1" (LH) | ||||||||
| MK522S-C10A-CF1 | NPT 3/8" | NPT 1" (RH) | |||||||
| MK522S-C10A-CF2 | NPT 1" (LH) | ||||||||
| MK522S-A15A-AG1 | PT 1/2" | PT 1 1/4" (RH) | 180 | 45 | 99 | 44 | 28 | ø94 | 55 |
| MK522S-A15A-AG2 | PT 1 1/4" (LH) | ||||||||
| MK522S-B15A-BG1 | PF 1/2" | PF 1 1/4" (RH) | |||||||
| MK522S-B15A-BG2 | PF 1 1/4" (LH) | ||||||||
| MK522S-C15A-CG1 | NPT 1/2" | NPT 1 1/4" (RH) | |||||||
| MK522S-C15A-CG2 | NPT 1 1/4" (LH) | ||||||||
| MK522S-A15A-AG1 | PT 3/4" | PT 1 1/4" (RH) | 189 | 45 | 102 | 45 | 28 | ø97 | 55 |
| MK522S-A15A-AG2 | PT 1 1/4" (LH) | ||||||||
| MK522S-B15A-BG1 | PF 3/4" | PF 1 1/4" (RH) | |||||||
| MK522S-B15A-BG2 | PF 1 1/4" (LH) | ||||||||
| MK522S-C15A-CG1 | NPT 3/4" | NPT 1 1/4" (RH) | |||||||
| MK522S-C15A-CG2 | NPT 1 1/4" (LH) | ||||||||
| MK522S-A20A-AG1 | PT 3/4" | PT 1 1/2" (RH) | 217 | 58 | 113 | 47 | 30 | ø100 | 55 |
| MK522S-A20A-AG2 | PT 1 1/2" (LH) | ||||||||
| MK522S-B20A-BG1 | PF 3/4" | PF 1 1/2" (RH) | |||||||
| MK522S-B20A-BG2 | PF 1 1/2" (LH) | ||||||||
| MK522S-C20A-CG1 | NPT 3/4" | NPT 1 1/2" (RH) | |||||||
| MK522S-C20A-CG2 | NPT 1 1/2" (LH) | ||||||||
| MK522S-A25A-AH1 | PT 1" | PT 1 1/2" (RH) | 225 | 58 | 122 | 51 | 30 | ø100 | 65 |
| MK522S-A25A-AH2 | PT 1 1/2" (LH) | ||||||||
| MK522S-B25A-BH1 | PF 1" | PF 1 1/2" (RH) | |||||||
| MK522S-B25A-BH2 | PF 1 1/2" (LH) | ||||||||
| MK522S-C25A-CH1 | NPT 1" | NPT 1 1/2" (RH) | |||||||
| MK522S-C25A-CH2 | NPT 1 1/2" (LH) |
