| Media | Air, Gas, Water etc. |
| Max. Pressure | 400 kgf/cm² |
| Max. Temperature | 120℃ |
| Max. Rotation Speed | 1,500 rpm |
사용유체, 온도, 압력, RPM에 따라 재질 변경됩니다.
문의를 바랍니다.
| MODEL | A | B | L | L1 | L2 | H | D | D1 |
| MK241S-10A-AC1 | PT 3/8" | PT 3/8" (RH) | 108 | 25 | 15 | 24 | ø52 | ø10 |
| MK241S-10A-AC2 | PT 3/8" (LH) | |||||||
| MK241S-10A-BC1 | PF 3/8" | PF 3/8" (RH) | ||||||
| MK241S-10A-BC2 | PF 3/8" (LH) | |||||||
| MK241S-10A-CC1 | NPT 3/8" | NPT 3/8" (RH) | ||||||
| MK241S-10A-CC2 | NPT 3/4" (LH) | |||||||
| MK241S-15A-AD1 | PT 1/2" | PT 1/2" (RH) | 115 | 32 | 17 | 24 | ø52 | ø11 |
| MK241S-15A-AD2 | PT 1/2" (LH) | |||||||
| MK241S-15A-BD1 | PF 1/2" | PF 1/2" (RH) | ||||||
| MK241S-15A-BD2 | PF 1/2" (LH) | |||||||
| MK241S-15A-CD1 | NPT 1/2" | NPT 1/2" (RH) | ||||||
| MK241S-15A-CD2 | NPT 1/2" (LH) | |||||||
| MK241S-20A-AE1 | PT 3/4" | PT 3/4" (RH) | 138 | 37 | 21 | 30 | ø70 | ø12 |
| MK241S-20A-AE2 | PT 3/4" (LH) | |||||||
| MK241S-20A-BC1 | PF 3/4" | PF 3/4" (RH) | ||||||
| MK241S-20A-BC2 | PF 3/4" (LH) | |||||||
| MK241S-20A-CC1 | NPT 3/4" | NPT 3/4" (RH) | ||||||
| MK241S-20A-CC2 | NPT 3/4" (LH) |
