| Media | Air, Hydraulic oil etc. |
| Max. Pressure | Air : 10 kgf/cm² Hydraulic oil : 200 kgf/cm² |
| Max. Temperature | 120℃ |
| Max. Rotation Speed | 250 rpm |
사용유체, 온도, 압력, RPM에 따라 재질 변경됩니다.
문의를 바랍니다.
| MODEL | B | A | L | L1 | L2 | L3 | H | D | D1 |
| MK512S-A8A-AB1 | PT 1/4" | PT 1/4" (RH) | 85 | 53 | 24 | 13 | 24 | ø53 | ø6 |
| MK512S-A8A-AB2 | PT 1/4" (LH) | ||||||||
| MK512S-B8A-BB1 | PF 1/4" | PF 1/4" (RH) | |||||||
| MK512S-B8A-BB2 | PF 1/4" (LH) | ||||||||
| MK512S-C8A-CB1 | NPT 1/4" | NPT 1/4" (RH) | |||||||
| MK512S-C8A-CB2 | NPT 1/4" (LH) | ||||||||
| MK512S-A10A-AC1 | PT 3/8" | PT 3/8" (RH) | 85 | 53 | 24 | 13 | 24 | ø53 | ø8 |
| MK512S-A10A-AC2 | PT 3/8" (LH) | ||||||||
| MK512S-B10A-BC1 | PF 3/8" | PF 3/8" (RH) | |||||||
| MK512S-B10A-BC2 | PF 3/8" (LH) | ||||||||
| MK512S-C10A-CC1 | NPT 3/8" | NPT 3/8" (RH) | |||||||
| MK512S-C10A-CC2 | NPT 3/8" (LH) | ||||||||
| MK512S-A15A-AD1 | PT 1/2" | PT 1/2" (RH) | 110 | 70 | 33 | 18 | 27 | ø12 | ø12 |
| MK512S-A15A-AD2 | PT 1/2" (LH) | ||||||||
| MK512S-B15A-BD1 | PF 1/2" | PF 1/2" (RH) | |||||||
| MK512S-B15A-BD2 | PF 1/2" (LH) | ||||||||
| MK512S-C15A-CD1 | NPT 1/2" | NPT 1/2" (RH) | |||||||
| MK512S-C15A-CD2 | NPT 1/2" (LH) | ||||||||
| MK512S-A20A-AE1 | PT 3/4" | PT 3/4" (RH) | 150 | 80 | 41 | 22 | 36 | ø16 | ø12 |
| MK512S-A20A-AE2 | PT 3/4" (LH) | ||||||||
| MK512S-B20A-BE1 | PF 3/4" | PF 3/4" (RH) | |||||||
| MK512S-B20A-BE2 | PF 3/4" (LH) | ||||||||
| MK512S-C20A-CE1 | NPT 3/4" | NPT 3/4" (RH) | |||||||
| MK512S-C20A-CE2 | NPT 3/4" (LH) |
